Key features & benefits

• Battery pack options: 9.6 kWh / 10.8 kWh / 14.4 kWh (AGM DC12) and 11 kWh / 16.56 kWh (lithium DC24).​

• Solar array: 3 × 435 W LONGi brand solar panels for fast charging (full charge in about 7.3 hours, up to 21 hours continuous discharge).​

• LED lighting: adjustable angle and brightness LED light set, with optional number and power of fixtures to match each site.​

• Easy deployment: compact, single‑axle trailer with guide wheel, easy to tow and set up outdoors.​

• Long service life: designed to serve more than 12 years, zero emissions and zero noise.​

Technical specifications

Trailer & mast

• Trailer type: single axle.​

• Mast: manual / electric / hydraulic, extendable 20–30 ft.​

• Tire and rim size: 15″.​

• Stabilizer supports: 4 × manual.​

• Drawbar: A‑frame or folded tongue.​

• Tow hitch: 2″ ball hitch or 70 mm ring.​

• Mud guards / wheel chocks: special design for stability.​

Electrical system

• System voltage options: DC12 V, DC24 V, DC48 V (depending on battery configuration).​

• Backup generator (optional):

  • 3 kW gas generator

  • 3 kW diesel generator

  • or no generator (full solar/battery).​

• Working temperature: -35 to 60 °C.​

• Solar charger controller (MPPT): Victron MPPT or Chinese MPPT (configurable).​

• AC charger: optional (YES/NO depending on configuration).​

• Protection level: IP65.​

• Wind rating speed: up to 100 km/h.​

Battery options

• AGM battery (DC12 V):

  • 9.6 kWh (4 × 200 Ah)

  • 10.8 kWh (6 × 150 Ah)

  • 14.4 kWh (6 × 200 Ah)​

• Lithium battery (DC24 V):

  • 11 kWh (2 × 230 Ah)

  • 16.56 kWh (3 × 230 Ah)​

LED lighting system

• LED light numbers: 4 / 6 / 8 fixtures selectable.​

• LED power options: 60 W, 100 W, 200 W, 250 W (per fixture).​

• Photocell switch: optional (NO / YES).​

• LED efficacy: 180 lumens/W.​

• LED light angle adjustment: NO / manual / electric (depending on configuration).​

• LED light bar steering: NO / manual / electric.​

Dimensions & container loading

Trailer dimensions (two options)

• Length (without tongue): 2100 mm (Option 1 & 2).​

• Width (including fender): 1700 mm (Option 1) / 1400 mm (Option 2).​

• Height (mast retracted): 2300 mm.​

• Weight (with all equipment): 1300 kg.​

Container loading capacity

• 20 ft container: 3 units (Option 1) / 4 units (Option 2).​

• 40 ft container: 7 units (Option 1) / 8 units (Option 2).​

Product advantages

• Zero emissions and zero noise, perfect for green projects and noise‑sensitive environments.​

• Long autonomy (up to 7 days) and fast solar charging, reducing or eliminating fuel usage.​

• Highly configurable LED lighting system (number, power, angle, steering) to suit any terrain and application.​

• Robust IP65 protection and high wind rating for harsh outdoor conditions.
